White balance:
White
Balance Cool Normal Warm
RGB
Cool R Drive
Gray Scale
Normal G Drive
Pattern
Warm B Drive
R Cut off
G Cut off
B Cut off
2) Input RGB signal.
High light 75%
Low light 15% 3) Copy PC R,G,B drive and cut off data of each white
balance mode to RGB position.
INPUT Alignment menu ProcedureEquipment Setting
5 Picture: 1) Write down each color temaparature of R,G,B drive and
Normal Cut off data as follows.
Aspect:
16:9
White balance:
White
Balance Cool Normal Warm
DVI
Cool R Drive
Gray Scale
Normal G Drive
Pattern
Warm B Drive
R Cut off
G Cut off
B Cut off
2) Input NTSC signal.
High light 75%
Low light 15% 3) Copy PC R,G,B drive and cut off data of each white
balance mode to DVI position.
6 Picture: 1) Write down each color temaparature of R,G,B drive and
Normal Cut off data as follows.
Aspect:
16:9
24
TH-50PHW7BX / TH-50PHW7EX / TH-50PHD7EK / TH-50PHD7ES / TH-50PHD7BK / TH-50PHD7BS / TH-50PHD7UY
