8
TH-65PF12EK
4 Specifications
Power Source 220 - 240 V AC, 50/60Hz
Power Consumption
Power on 700 W
Stand-by condition Save OFF 1.2 W, Save ON 0.7 W
Power off condition 0.4 W
Plasma Display panel Drive method: AC type 65-inch,
16:9 aspect ratio
Screen size 1,434 mm (W) × 806 mm (H) × 1,645 mm (diagonal)
(No. of pixels) 2,073,600 (1,920 (W) × 1,080 (H)) [5,760 × 1,080 dots]
Operating condition
Temperature 0 °C - 40 °C
Humidity 20 % - 80 %
Applicable signals
Scanning format
525 (480) / 60i 60p, 625 (575) / 50i 50p, 750 (720) / 60p 50p, 1125 (1080) /
60i 60p 50i 50p 24p 25p 30p 24sF, 1250 (1080) / 50i
PC signals VGA, SVGA, XGA, SXGA
UXGA ..... (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
DVI-D IN Video Input DVI-D 24 Pin × 1
compliance with DVI Revision 1.0
Audio Input Stereo mini jack (M3) × 1
0.5 Vrms
Content Protection Compatible with HDCP 1.1
LAN
RJ45 10BASE-T / 100BASE-TX, compatible with PJLink
TM
COMPONENT / RGB IN Y / G (BNC) with sync 1.0 Vp-p (75-ohm)
P
B
/B (BNC), P
R
/R (BNC) 0.7 Vp-p (75-ohm)
Audio Input Stereo mini jack (M3) × 1
0.5 Vrms
PC IN (HIGH-DENSITY Mini-D-SUB 15PIN) Y or G with sync 1.0 Vp-p (75-ohm)
Y or G without sync 0.7 Vp-p (75-ohm)
B / P
B
/ C
B
: 0.7 Vp-p (75-ohm)
R / P
R
/ C
R
: 0.7 Vp-p (75-ohm)
HD / VD: 1.0 - 5.0 Vp-p (high impedance)
VBS (use HD port) with picture 1.0 Vp-p (high impedance)
without picture 0.3 Vp-p (high impedance)
Audio Input Stereo mini jack (M3) × 1
0.5 Vrms
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
SPEAKERS 8-ohm, 20 W [10 W + 10 W] (10 % THD)
Accessories Supplied
Remote Control Transmitter N2QAYB000432
Batteries 2 × R6 Size
Fixing band TMME203 × 1
Ferrite core J0KG00000014 × 2
Dimensions (W × H × D) 1,554 mm × 925 mm × 99 mm
Mass (weight)
main unit only approx. 59.0 kg net
with speakers approx. 65.0 kg
Note:
• Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
• This equipment complies with the EMC standards listed below.
EN55022, EN55024, EN61000-3-2, EN61000-3-3.
