Panasonic TX-51P950M - 2 Chassis Board Layout

2 Chassis Board Layout
Board-Name Function
A-Board Main Signal, Digital Converter,Line Filter
D-Board Deflection, High Voltage
LR-Board CRT Drive (R)
LG-Board CRT Drive (G)
LB-Board CRT Drive (B)
H-Board Rear terminal
DG-Board Digital Core,MPU,AV Switch
DC-Board Convergence
GK-Board Front Terninal,Power Switch,Front Control panel
KA-Board Blue light
6
TX-51P950M / TX-51P950X / TX-43P950M / TX-43P950X
