Panasonic TX-51P950M - 16 Mechanical Replacement Parts List

51" mechanical replacement parts list
Ref. No. Part No. Part Name & Description Remarks
3800A PROTECT TAPE
BSC29-0151E HIGH VOLTAGE DISTRIBUTE
1 D9ZZ00000106 VR or D9ZZ00000079
DCA9015 VM COIL
2 G0F100000006 DY
J0KF00000018 FERRITE CORE
19 K2CR2DZ00001 AC CORD(TX-51P950M/XB)
19 K2CT3DZ00006 AC CORD(TX-51P950XA)
K2DR53D00001 TRANSFORM SOCKET(TX-
51P950XA)
3 L0AA05A00063 SPEAKER
4 L0AA10A00022 SPEAKER
5 N2QAJB000109 REMOTE CONTROLLER
NO.720 PAPER TAPE
R6(DW)/2STA BATTERY
SC102HSC SILICA GEL
T4FM2515J TAPE
T5E7756 TAPE
T8C1710201H SILICA GEL
6 TBL0A8407 LEG-CASTER
TBM0A0257 OPERATE PANEL
TBM0A0258 AV PANEL
7 TBM0A0270 MODEL NAME PLATE(TX-
51P950M)
7 TBM0A0271 MODEL NAME PLATE(TX-
51P950XA)
7 TBM0A0281-1 MODEL NAME PLATE(TX-
51P950XB)
TBM0A3005 PANASONIC BADGE
TBX0A83701 POWER BUTTON
TBX0A83801 5-KEY BUTTON
TES0A203 SPRING
8 TKG0A9526 LENS
11 TKG0A9542 MIRROR
9 TKGH5077 SCREEN
10 TKGH5078 SCREEN
12 TKK0A8401 LED PANEL
13 TKK0A8527 REAR COVER
TKK0A8531 LED PANEL
14 TKP0AB1604 REAR AV BRACKET
TKP0AB2201 BAR
TKP0AB2301 DOOR
15 TKU0A2404A BACK COVER
16 TKU0A3401-1 BACK COVER
17 TKX0A1501-1 CABINER(RIGHT)
18 TKX0A1601-1 CABINER(RIGHT)
TKZ0A8808 SOLEPLATE
TKZ0A8811 BAR
TKZ0A8812 BAR
TMK0A013 FELT
TMK0A082 FELT
TMK0A086 FELT
TMK0A087 FELT
TMK0A090 FELT
TMK0A091 FELT
TMK0A098 FELT
TMK0A122 FELT
TMK0A123 FELT
TMK0A131 FELT
TMK0A136 FELT
TMK0A137 FELT
TMK0A153 FELT
TMK0A734 SPONGE
TMK0A756 SPONGE
TMK0A767 RUBBER MAT
TMM0A448 CLAMPER
TMZ0A9101 BAR
TMZ0A9501 BAR
TPC0A48601 CARTON BOX
TPC0A48702 CARTON BOX(TX-51P950M)
Ref. No. Part No. Part Name & Description Remarks
TPC0A48703 CARTON BOX(TX-51P950XA)
TPC0A48704 CARTON BOX(TX-51P950XB)
TPD0A1064 CUSHION
TPD0A2059 CUSHION
TPD0A5023 CUSHION
TPD0A5024 CUSHION
TPD0A5025 CUSHION
TPD0A9002L HANDLE
TPD0A9022 ROUND PAPER PIPE
TPD0A9031 MAT
TPD0A9034 BRACKET
TPE0A4020 PROTECT COVER
TPE0A4024 BAG
TQB0A1151 FAN BAG(TX-51P950M)
TQB0A1152 FAN BAG(TX-51P950XA)
TQB0A1156 FAN BAG(TX-51P950XB)
TQD0A12002 CHECK OUT TICKET
TUA0A0500-3 BRACKET
TUX0A132 OPERATE PANEL
20 TXCB1KZV PICTURE TUBE
21 TXCG1KYV PICTURE TUBE
22 TXCR1KZV PICTURE TUBE
23 TXFKJ01KYV SPEAKER BRACKET
24 TXFKJ11KYV SPEAKER BRACKET
25 TXFKP01HGC5 SPEAKER BOARD
26 TXFKY04HFC5 CABINET(BOTTOM)
27 TXFKY011KZV CABINET(TOP)
XTB4+20AFJK SCREW
YZ430BM FBT CORD or KFT7CM356F
YZ600BM FBT CORD or KFT7CM357F
43" mechanical replacement parts list
Ref. No. ITEM ITEM DESCRIPTION Remarks
3800A PROTECT TAPE
BSC29-0151E HIGH VOLTAGE DISTRIBUTE
1 D9ZZ00000106 VR or D9ZZ00000079
DCA9015 VM COIL
2 G0F100000006 DY
J0KF00000018 FERRITE CORE
19 K2CR2DZ00001 AC CORD(TX-43P950M/XB)
19 K2CT3DZ00006 AC CORD(TX-43P951XA)
K2DR53D00001 TRANSFORM SOCKET(TX-
43P950XA)
3 L0AA05A00063 SPEAKER
4 L0AA10A00022 SPEAKER
5 N2QAJB000109 REMOTE CONTROLLER
NO.720 PAPER TAPE
R6(DW)/2STA BATTERY
SC102HSC SILICA GEL
T4FM2515J TAPE
T5E7756 TAPE
T8C1710201H SILICA GEL
6 TBL0A8407 LEG-CASTER
TBM0A0257 OPERATE PANEL
TBM0A0258 AV PANEL
7 TBM0A0266 MODEL NAME PLATE(TX-
43P950M)
7 TBM0A0267 MODEL NAME PLATE(TX-
43P950XA)
7 TBM0A0280-1 MODEL NAME PLATE(TX-
43P950XB)
TBM0A3005 PANASONIC BADGE
TBX0A83701 POWER BUTTON
TBX0A83801 5-KEY BUTTON
TES0A203 SPRING
8 TKG0A9525 DRAWTUBE
9 TKG0A9534 SCREEN
10 TKG0A9535 SCREEN
11 TKG0A9536 MIRROR
12 TKK0A8401 LED PANEL
16 Mechanical Replacement Parts List
83
TX-51P950M / TX-51P950X / TX-43P950M / TX-43P950X
