VL-SVN511BX/VL-SVN511CX/VL-SVN511CX1
15.2. Replacement Parts List
Note:
1. RTL (Retention Time Limited)
The marking (RTL) indicates that the Retention Time is
limited for this item.
After the discontinuation of this assembly in production,
the item will continue to be available for a specific period
of time. The retention period of availability depends on
the type of assembly and the laws governing parts and
product retention. At the end of this period, the assembly
will no longer be available.
2. Important safety notice
Components identified by the mark indicates special
characteristics important for safety. When replacing any
of these components, only use specified manufacture's
parts.
3. The S mark means the part is one of some identical
parts. For that reason, it may be different from the
installed part.
4. ISO code (Example : ABS-HB) of the remarks column
shows quality of the material and a flame resisting grade
about plastics.
5. RESISTORS & CAPACITORS
Unless otherwise specified;
All resistors are in ohms (), k=1000, M=1000k
All capacitors are in MICRO FARADS (F), p=(F)
15.2.1. Main Monitor Station
15.2.1.1. Cabinet and Electrical Parts
(*1) When replacing LCD of main monitor station, make adjust-
ments in "WHITE BALANCE". (Refer to White Balance
Adjustment (P.50)).
15.2.1.2. Main P.C. Board Parts
(*2) When replacing IC401, refer to Things to do after
replacing IC (P.46).
(*3) When replacing IC401, IC405 or X401, make adjustments.
(Refer to When replacing BBIC and X'tal (P.47)).
Safety Ref.
No.
Part No. Part Name & Description Remarks
1 PNBC1618Z1 OFF BUTTON ABS-V0
S
2 PNBC1617Z1 TALK BUTTON ABS-V0
S
3 PNYMAN511EX CABINET BODY ABS-V0,
PC-HB
4 PNHR1698Z LED LENS PS-HB
5 L0AA02A00087 SPEAKER
6 PNHG1148Z SPEAKER RUBBER
7 PNBC1604Z1 NAVI BUTTON ABS-V0
S
8 PNBC1603Z1 FUNCTION BUTTON ABS-V0
S
9 L5EDDYY00671 LIQUID CRYSTAL DISPLAY
(*1)
10 PNHR2159Z LCD HOLDER ABS-V0
11 PNKF1403Z1 CABINET COVER PS-HI-
V0 S
12 PNKV1236Z1 DC CORD COVER ABS-V0
S
13 PNGT9471Z NAME PLATE
14 PNMG1012Z MIC COVER Si
A XTN3+10GFJ SMAL SCREW
B XTB26+10GFJ SMALL SCREW
C XTW26+T8PFJ TAPPING SCREW
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB1 PNWPAN511BX MAIN BOARD ASS'Y
(ICs)
IC100 MN103SW55 IC
IC101 C0EBY0000665 IC
IC300 C3ABQY000101 IC
IC340 C0DBAYY01630 IC
IC390 C1ZBZ0004359 IC
IC401 C3EBJY000044 IC (*2)(*3)
IC402 PNWIAN511BX IC
IC405 C1CB00004202 IC (*3)
IC500 C0ABBB000179 IC
IC670 C1AB00002793 IC
IC671 C0DBGYY02061 IC
IC700 B3PBA0000138 PHOTO ELECTRIC TRANS-
DUCER
IC701 C0ABBB000179 IC
IC910 C0DBAYY01694 IC
IC920 C0DBAYY01694 IC
IC930 C0DBAYY01694 IC
IC960 C0DBGYY03592 IC
IC970 C0ABBA000159 IC
IC350 It is impossible to supply (IC350 and IC490)
by itself. Therefore, when this part is in
need of replacing, please replace the Main
Board Ass'y (PCB1).
IC490
(TRANSISTORS)
Q100 DRC9114E0L TRANSISTOR(SI)
Q230 B1CHPC000014 TRANSISTOR(SI)
Q281 B1GBCFYY0014 TRANSISTOR(SI)
Q401 DSA7003R0L TRANSISTOR(SI)
Q402 B1ADGE000012 TRANSISTOR(SI)
Q610 B1GDCFGJ0008 TRANSISTOR(SI)
Q620 B1GDCFGJ0008 TRANSISTOR(SI)
Q640 B1GBCFYY0014 TRANSISTOR(SI)
Q650 B1ADBL000017 TRANSISTOR(SI)
Q651 B1ADMJ000003 TRANSISTOR(SI)
Q652 B1ADBL000017 TRANSISTOR(SI)
Q653 B1ADMJ000003 TRANSISTOR(SI)
Q654 B1GBCFJK0001 TRANSISTOR(SI)
Q700 B1GBCFYY0014 TRANSISTOR(SI)
Safety Ref.
No.
Part No. Part Name & Description Remarks
To Next Page
