Panasonic WV-SW458

Image capture mode Explanation
2M Double Panorama [16:9] Double Panorama images with an aspect ratio of 16:9 are transmitted.
The maximum image capture size that can be configured is
2 megapixel (1920(H)x1080(V)).
1M Double Panorama [16:9] Double Panorama images with an aspect ratio of 16:9 are transmitted.
The maximum image capture size that can be configured is
1 megapixel (1280(H)x720(V)).
1.3M Quad PTZ [4:3] Quad PTZ images with an aspect ratio of 4:3 are transmitted.
The maximum image capture size that can be configured is
1.3 megapixel (1280(H)x960(V)).
1.3M Single PTZ [4:3] Single PTZ images with an aspect ratio of 4:3 are transmitted.
The maximum image capture size that can be configured is
1.3 megapixel (1280(H)x960(V)).
Double Panorama + Quad PTZ 2 megapixel Double Panorama images (with an aspect ratio of 16:9)
and 1.3 megapixel Quad PTZ images (with an aspect ratio of 4:3) can
be transmitted at the same time.
Double Panorama + Single PTZ 2 megapixel Double Panorama images (with an aspect ratio of 16:9)
and 1.3 megapixel Single PTZ images (with an aspect ratio of 4:3) can
be transmitted at the same time.
2M Panorama [16:9] Panorama images with an aspect ratio of 16:9 are transmitted.
The maximum image capture size that can be configured is
2 megapixel (1920(H)x1080(V)).
1M Panorama [16:9] Panorama images with an aspect ratio of 16:9 are transmitted.
The maximum image capture size that can be configured is
1 megapixel (1280(H)x720(V)).
Panorama + Quad PTZ 2 megapixel Panorama images (with an aspect ratio of 16:9) and
1.3 megapixel Quad PTZ images (with an aspect ratio of 4:3) can be
transmitted at the same time.
Panorama + Single PTZ 2 megapixel Panorama images (with an aspect ratio of 16:9) and
1.3 megapixel Single PTZ images (with an aspect ratio of 4:3) can be
transmitted at the same time.
3M Fisheye [4:3] Fisheye images with an aspect ratio of 4:3 are transmitted.
The maximum image capture size that can be configured is
3 megapixel (2048(H)x1536(V)).
1.3M Fisheye [4:3] Fisheye images with an aspect ratio of 4:3 are transmitted.
The maximum image capture size that can be configured is
1.3 megapixel (1280(H)x960(V)).
VGA Quad streams [4:3] Only H.264 images can be transmitted with quad streams for VGA.
1.2.3 Image types
1. Double Panorama
In Double Panorama, the panorama image is displayed with distortion correction performed on a 180° image
for both the top and bottom parts of a fisheye image.
10 Operating Instructions
1 Monitor images on a PC
