Chapter 3: Installation
11
Desk-Mount
The IPR512 Receiver can be mounted on a desk. Prior to mounting the unit, ensure that the
surface is free of any obstacles.
Required Materials:
Desktop Installation Kit (included)
Phillips screwdriver
Guidelines
Ensure that at least 1U is allocated for the IPR512 Receiver.
Ensure surface for desk-mount installation is stable.
Ensure a clear path behind the receiver for wiring.
To Desk-Mount the IPR512 Receiver
1. Secure Desktop Mounting Feet to the IPR512 Receiver, as shown in Figure 6: Desk-
Mounted IPR512 Receiver.
2. Position IPR512 Receiver on desk, ready for wiring.
Figure 6: Desk-Mounted IPR512 Receiver
Phillips Pan
Type B Screw
Desk-Mounting
Feet
