Chapter 2: Overview
7
IPR512 Receiver Technical Specifications
The following table describes the technical specifications of the IPR512 Receiver.
Table 2: IPR512 Receiver Technical Specifications
IPR512 Receiver Dimensions
The following table provides the dimensions and weight of the IPR512 Receiver.
Table 3: IPR512 Receiver Dimensions
Figure 2: IPR512 Receiver Dimensions
Input Voltage 100-240 VAC (50-60 Hz)
Input Power 10W
Output Voltage 12VDC
Operating Temperature 0°C to +50°C (32°F - 122°F)
Height Width Depth Weight
4.2 cm (1.66 in.) 42.8 cm (16.84 in.) 30.4 cm (11.96 in.) 3.28 kg (7.2 lbs.)
30.4 cm
4.2 cm
42.8 cm
