Parker 598P - Optoisolator Trigger Board Terminal Assignment; Quad

13 of 20
598P/599P Application Manual
OPTOISOLATOR TRIGGER BOARD TERMINAL ASSIGNMENT
4 Quad
12
T1
10
T10
8
T3
6
T12
4
T5
2
T8
11
+24
9
+24
7
+24
5
+24
3
+24
1
+24
1
T7
3
T4
5
T9
7
T6
9
T11
11
T2
2
+24
4
+24
6
+24
8
+24
10
+24
12
+24
TH1 TH10 TH3 TH12 TH5 TH8
TH7 TH4 TH9
TH11TH6 TH2
TBS
TBM
AH057915U004
2 Quad
1
T1
3
T4
5
T3
7
T6
9
T5
11
T2
2
+24
4
+24
6
+24
8
+24
10
+24
12
+24
TH1 TH4 TH3 TH6 TH5 TH2
TBM
AH057915U003
