598P/599P Application Manual
OPTOISOLATOR FIRING BOARD TERMINAL LAYOUT AND DIMENSIONS
Version 1
C1
C2
C3
C4
A1
A2
A3
A4
A5
A6
K K G
0V
0V
+24V
+24V
Relay
Relay
Signal
Signal
+24V
+24V
Signal from
Trigger Board
24V External
Supply
Thyristor
Trip Interlock
Closed when
External Supply On
> 2 amp
+24V Supply On
58mm
84mm
135mm
150mm
6.5mmDia
Transformer Earth ScreenGnd
Cascade Signal
to extra Amplifiers
for Parallel Stacks
