Parker 598P - Legacy Product Code

17 of 20
598P/599P Application Manual
LEGACY PRODUCT CODE
Block Variable Description
1
XXXX
Product
598P : 590+ External Stack Controller 4Q DC Drive
599P : 591+ External Stack Controller 2Q DC Drive
2
XXXX
Four Digits describing the Maximum Field DC Current Output.
0060 = 60 Amps
0120 = 120 Amps
3
XXX
Three Digits describing the Nominal 3 Phase Supply Voltage.
240 = 110 to 240 Vac ±10% 50/60Hz. – Low Voltage Build.
500 = 220 to 500 Vac ±10% 50/60Hz. – Medium Voltage Build.
690 = 380 to 690 Vac ±10% 50/60Hz. – High Voltage Build.
4
XXXX
Four Digits describing the Mechanical Package Style.
First Two Digits Livery
00 Standard
05 Distributor
Third Digit Firing Amplifier
T Trigger (110-220v & 220-500v supply only)
A Power Amplifier
Fourth Digit Operator Station
0 No Opstation
1 6901 Opstation
5
through
7
As 590+.
8
XXX
Three Digits defining the required Auxiliary Supply Voltage.
0 = Universal Supply. 110 to 240 Vac ±10% 50/60Hz. 60 Amp Product only.
115 = 110 to 120 Vac ±10% 50/60Hz. 120 Amp Product requirement.
230 = 220 to 240 Vac ±10% 50/60Hz. 120 Amp Product requirement.
9
XXX
Special Options.
