Parker Compax3 Start-Up

START UP
4 192-120112 N1 C3 Start up March 2004
1.1 Aim of this manual
You can read about the following in this chapter:
Task: Setting up Compax3, moving the motor ..................................................................................4
Required components.......................................................................................................................4
Described below is the setup of a motor without load.
Please heed the safety instructions and the device assignment in the
Compax3 installation manual (19x-120102)
1.1.1. Task: Setting up Compax3 , moving the motor
! Simple and independent of the Compax3 device variant
! Without overhead for configuration
! Without special knowledge in programming
1.1.2. Components required
! Compax3 device
V2 = 230V device V4 = 400V device
! Power supply voltage
230 VAC 400 VAC
! 24 VDC voltage supply
24 VDC 24 VDC
! Plug set
ZBH 02/01 C3 Sxxx: ZBH02/02
C3 S300: ZBH02/03
! Motor
! Motor cable
! Resolver cable
! RS232 interface cable
! Compax3 CD

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
