Parker Compax3 Start-Up

START UP
14 192-120112 N1 C3 Start up March 2004
1.4.1. Commissioning
Described below is the setup of a motor without load.
Define test motion parameters........................................................................................................15
Execute test motion ........................................................................................................................17
Display of the values in the oscilloscope and in the status display ..................................................19
! Click on the "Enter test move parameters" button in the setup window (next
picture below).

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
