Parker Compax3 Start-Up

Parker EME
Preparation
Installation of the C3 ServoManager
192-120112 N1 C3 Start up March 2004 5
english
1.2 Preparation
Described below is the setup of a motor without load.
Installation of the C3 ServoManager.................................................................................................5
Required wiring.................................................................................................................................6
1.2.1. Installation of the C3 ServoManager
The Compax3 ServoManager can be installed directly from the Compax3 CD.
Click on the appropriate hyperlink or start the installation program
"C3Mgr_Setup_V.... .exe" and follow the instructions.
Minimum requirements
For successful installation, your PC must meet the following minimum
requirements:
! Windows NT 4.0 (Intel) with Service Pack 6, Windows 2000 or Windows XP.
! Administrator authorisation* on the system
! Microsoft Internet Explorer 4.01 (SP2) or higher
! Pentium-PC (300 MHz or faster is recommended)
! 64 MB RAM (128 MB recommended)
! Required HD capacity
! CD-Installation: 350 MB before installation, 200 MB after installation
! Super VGA-Monitor (with a resolution of at least 800 x 600, setting: small fonts)

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
