61 - PVD 3674_GB_K Series_CE-November 2016.Docx
4.3. Electrical connections
Danger: Do not connect the kit to any electric supply . Only the motor
can be connected to an electric supply.
Danger: never connect the motor to a drive with a DC bus higher
than:
- 155VDC for sizes 32, 44, 64 and 89
- 340VDC for size 178.
Danger: Check that the power to the electrical cabinet is off prior to
making any connections.
Caution: The wiring must comply with the drive commissioning
manual and with recommended cables.
Caution: Section motor cable is lower than commissioning section
cable between motor and drive due to high performance motor cable
design. Do not take the same cable section than motor.
Danger: The kit must be earthed by connecting to an unpainted
section of the motor.
Caution: The motor cables are designed for high current density, so
cable surface can reach temperatures exceeding 100°C.
Caution: After 15 days, check all tightening torques on cable
connection.
Please, read §3.6 "Power Electrical connection" to have information about cable.
