Parker PHD Series - PHD50;PHD70 Frequency Input Capabilities

12 PHD
Connectors
PHD70 J2 Connector Pinout
Pin
Function
1
GPIO10 (digital or frequency input/low power output)
2
GPIO9 (digital or frequency input/low power output)
3
CAN2_SHLD
4
CAN2_L
5
CAN2_H
6
VIDEO1_GND
7
VIDEO1
8
VIDEO2
9
VIDEO2_GND
10
P12V0 (12V regulated supply)
11
Ground
12
Ground
13
GPIO8 (digital input)
14
P5V0 (5V sensor supply)
15
RS232-RX (debugging use only)
16
RS232-TX (debugging use only)
17
NC
18
NC
19
NC
20
NC
