Parker PHD Series User Manual

39
Serial Ethernet Recovery Flexcan (SERF) Development Board
Name
Description
Jumper Position
Pins
Usage Comments
J7
GPIO_7
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J8
GPIO_6
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J9
GPIO_5
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J11
GPIO_4
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J12
GPIO_3
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J14
GPIO_2
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J15
GPIO_1
1 to 2
Enable GPIO switch input.
2 to 3
Intended for factory use.
Removed
Enable daughter board input.
J23
Audio 1
1 to 2
Not enabled on the Standard
products, intended for future use.
2 to 3
Not enabled on the Standard
products, intended for future use.
J24
Audio 2
1 to 2
Not enabled on the Standard
products, intended for future use.
2 to 3
Not enabled on the Standard
products, intended for future use.
