PDL MICRODRIVE-3 User Manual

Microdrive Series Instruction Manual
4201-109 Rev I
31
THE DISPLAY:
STATUS LINE ð STP 0.0A +0.0Hz ï ALWAYS DISPLAYED
CONTROL LINE ð T=0.0% R= +0.0Hz ï CAN BE SCROLLED TO SEE MANY OTHER SCREENS
Table 1.1 Display Screen Messages - Short Menus
STATUS LINE:
SCREEN DESCRIPTION NOTES
STP 0.0A +0.0Hz STATUS ALWAYS DISPLAYED
CONTROL LINE:
Note: Default (factory set) values are shown in the control line where appropriate.
LOCAL CONTROLS:
NO. SCREEN DESCRIPTION MIN/MAX UNITS
-3 00000000 00 00 CONTROL INPUT DISPLAY ; % ;%
-2 KB FREQ= +0.0Hz KEYBOARD FREQUENCY CONTROL -200/+200 HERTZ
-1 STOP-RST START KEYBOARD STOP/RESETSTART - -
EXTENDED STATUS SCREENS:
NO. SCREEN DESCRIPTION UNITS
0 T=0.0% R= +0.0Hz MOTOR TEMPERATURE; REFERENCE FREQ. %, HERTZ
1 Vdc=565V Vo=400V DC BUS VOLTAGE; OUTPUT VOLTAGE V(DC);V(AC)
2 NO FAULTS FAULT DISPLAY
ADJUSTMENT SCREENS:
NO. SCREEN DESCRIPTION MIN/MAX UNITS
10 10 MTR CUR= I(Inv.) RATED (NAMEPLATE) MOTOR CURRENT 0.20/1.50xI(Inv.) AMPS
11 11 MTR VOLT=415V RATED (NAMEPLATE) MOTOR VOLTAGE 10/995 AC VOLTS
12 12 MTR FR = 50Hz RATED (NAMEPLATE) MOTOR FREQUENCY 10/250 HERTZ
14 14 BOOST = 0.0% TORQUE BOOST VOLTAGE AT ZERO SPEED 0.0/15.0 %V(MOTOR)
15 15 ACC1=10.0Hz/s ACCELERATION RATE (NORMAL) 0.02/500 HERTZ/SEC
16 16 DEC1=10.0Hz/s DECELERATION RATE (NORMAL) 0.02/500 HERTZ/SEC
23 23 FR F1= +0.0Hz REFERENCE FREQUENCY SETPOINT 1 -200/+200 HERTZ
24 24 FR F2=+60.0Hz REFERENCE FREQUENCY SETPOINT 2 -200/+200 HERTZ
42 42 DEC3=10.0Hz/s EMERGENCY STOP DECELERATION RATE 0.02/500 HERTZ/SEC
SCREEN CONTROLS:
NO. SCREEN DESCRIPTION OPTIONS
95 95 ENGLISH LANGUAGE SELECTION ENGLISH/DEUTSCH/ESPANOL/NEDERLANDS
96 96 SHORT MENUS=N MENU PRESENTATION SHORT [Y] / FULL [N]
97 97 INITIALISE =N INITIALISE ALL SETTINGS [Y]ES / [N]O
98 98 COMMISSION =Y COMMISSION MODE [Y]ES / [N]O
WARNING MESSAGES:
MESSAGE MEANING/NOTES
STOP TO ALTER ADJUSTMENT CAN ONLY BE MADE WITH DRIVE STOPPED
ILLEGAL ACCESS DRIVE MUST BE IN COMMISSIONING MODE TO ADJUST SETTINGS
NO KEYBD CONTROL KEYBOARD CONTROLS ARE NOT ENABLED
INITIALISING DRIVE BEING INITIALISED TO FACTORY DEFAULT SETTINGS
Note: 1. Standard Configuration values are shown.
2. Full menus are shown in Full Menu Table.
3. Although not shown, full adjustments and modes are always active.
4. Refer to detail of full menus for more information.
