PDL MICRODRIVE-3 User Manual

Microdrive Series Instruction Manual
4201-109 Rev I
32
Table 1.1 Display Screen Messages - Short Menus
STATUS LINE - PERMANENT STATUS MESSAGE
SCREEN:
XXX Y 0.0A +0.0HZ
XXX Y (FLASHING)
STP = STOPPED i = CURRENT EXCEEDS DRIVE RATING
SPG = STOPPING m = CURRENT EXCEEDS MOTOR CAPABILITY
RDY = READY
RUN = RUN
INC = INCHING
ACC = ACCELERATING 0.0A = OUTPUT CURRENT
DEC = DECELERATING
ILT = CURRENT LIMITING +0.0Hz = OUTPUT FREQUENCY
VLT = VOLTAGE LIMITING
HST = HOST STOP (SERIAL COMMS.)
FLT = FAULT TRIP
CONTROL STATUS DISPLAY (SCREEN -3)
The Control Status Display directly indicates the status of all control inputs
00000000 00 00
12345678 Vdc mA
CODE FUNCTION INPUT DISPLAY INDICATION
1 MULTIFUNCTION 1 T8 0 = LOW ; 1 = HIGH
2 MULTIFUNCTION 2 T9 0 = LOW ; 1 = HIGH
3 MULTIFUNCTION 3 T10 0 = LOW ; 1 = HIGH
4 MULTIFUNCTION 4 T11 0 = LOW ; 1 = HIGH
5 MULTIFUNCTION 5 T12 0 = LOW ; 1 = HIGH
6 MOTOR PTC T14 0 = LOW ; 1 = HIGH
7 PULSE TACHO T17 0 = LOW ; 1 = HIGH
8 RX (SERIAL COMMS.) 0 = LOW ; 1 = HIGH
Vdc 0-10Vdc T20 0 - 100(%)= 0-10Vdc
mA 4-20mA T22 0 - 100(%)= 4-20mA
FAULT MESSAGES (SCREEN 2)
Fault messages are automatically shown on the second line of the display.
SCREEN DESCRIPTION TRIP POINT (NOTES)
NO FAULTS NO FAULTS PRESENT -
LVDC SUPPLY LOW FAILURE OF +24V OR +15V SUPPLIES 22V/12V
SUPPLY FAULT INPUT PHASE VOLTAGE IMBALANCE 40Vac IN DC BUS
OVERVOLTAGE TRIP DC BUS OVERVOLTAGE 800Vdc
LOW MAINS SUPPLY LOW MAINS SUPPLY 400Vdc/280Vac
O/P I IMBALANCE OUTPUT CURRENT IMBALANCE +/- 30%
OVERCURRENT TRIP EXCESSIVE OUTPUT CURRENT 180% OF RATED CURRENT
IGBT/SLAVE FAULT MAIN SEMICONDUCTOR OVERLOAD SHORT CIRCUIT / OTHER
BRAKE THERM TRIP DYNAMIC BRAKE OVERLOAD SET BY BRAKE THERMAL MODEL
MOTOR THERM TRIP MOTOR THERMAL MODEL OVERLOAD SET BY MOTOR THERMAL MODEL
MOTOR MICROTHERM MOTOR THERMAL SENSOR TRIP SET BY MOTOR SENSOR
DRIVE THERM TRIP DRIVE THERMAL MODEL OVERLOAD SET BY DRIVE THERMAL MODEL
DRIVE MICROTHERM HEATSINK TOO HOT 90 DEG CELSIUS
MOTOR STALLED MOTOR STALLED FOR TOO LONG ILT T/O (SEE SCREEN 19)
GROUND FAULT GROUND FAULT ON DRIVE OUTPUT INTERNALLY SET
CALIBRATION FLT INTERNAL DRIVE FAULT (REQUIRES SERVICE)
DATA CORRUPTED NON-VOLATILE MEMORY ERROR (ALL DRIVE DATA IS RESET)
EEPROM FAILURE INTERNAL FAULT (REQUIRES SERVICE)
INVALID SOFTWARE INCORRECT VERSION EPROM (REQUIRES SERVICE)
HOST TRIP HOST COMPUTER TRIP -
COMMS TIMEOUT SERIAL COMMUNICATIONS TIMEOUT COMMS T/O (SEE SCREEN 74)
