PDL MICRODRIVE-3 User Manual

Microdrive Series Instruction Manual
4201-109 Rev I
45
MODE SCREENS:
NO. SCREEN DESCRIPTION OPTIONS
60 60 STR MODE=RAMP STARTING MODE NORMAL [RAMP] / [SPINNING]
61 61 STP MODE=RAMP STOPPING MODE [RAMP] DECELERATION / [SPIN] - DC BRAKE
62 62 REGEN=V-CLAMP REGENERATION MODE [D]YNAMIC [BRAKE] / [V]OLTAGE [CLAMP]
63 63 KEYBD CONT.=N LOCAL KEYBOARD CONTROL [Y]ES / [N]O
64 64 REF FR= V/mA REFERENCE FREQUENCY SOURCE
65 65 FB SRC=O/LOOP FEEDBACK SOURCE
66 66 I/P MODE =01 MULTIFUNCTION INPUT MODE SELECT 0/18
67 67 O/P RELAY1=00 OUTPUT RELAY 1 MODE SELECT 0/13
68 68 O/P RELAY2=03 OUTPUT RELAY 2 MODE SELECT 0/13
69 69 O/P RELAY3=05 OUTPUT RELAY 3 MODE SELECT 0/13
70 70 ANALOG O/P=00 ANALOGUE OUTPUT MODE SELECT 0/6
71 71 REV INHIBIT=N REVERSE LOCK OUT [Y]ES / [N]O
72 72 SWITCH FR =WW MODULATION FREQUENCY [NB] / [WW] / [NL] / [WL]
73 73 HV LOW TRIP=N MAINS POWER LOSS RESPONSE [Y]ES / N[O]
74 74 COMMS T/O=OFF COMMUNICATIONS TIMEOUT [OFF] / [1s] / [5s] / [25s]
75 75 I LIM MODE= I CURRENT LIMIT MODE [I] CURRENT / [TQ] TORQUE
76 76 I LIM SRC= 00 CURRENT LIMIT SOURCE 00/01/02
77 77 AUTOBOOST=Y AUTOMATIC BOOST CONTROL [Y]ES / [N]O
78 78 MIN FREQ RUN=N MINIMUM FREQUENCY RUN MODE [Y]ES / [N]O
79 79 MFI INVERT = N MULTI-FUNCTION INPUT INVERSION [Y]ES / [N]O
SCREEN CONTROLS:
NO. SCREEN DESCRIPTION OPTIONS
95* 95 ENGLISH LANGUAGE SELECTION ENGLISH/DEUTSCH/ESPANOL/NEDERLANDS
96* 96 SHORT MENUS=N MENU PRESENTATION SHORT [Y] / FULL [N]
97* 97 INITIALISE =N INITIALISE ALL SETTINGS [Y]ES / [N]O
98* 98 COMMISSION =Y COMISSION MODE [Y]ES / [N]O
* Present in Short Menus
FEEDBACK SOURCES (SCREEN 65)
CODE FEEDBACK SOURCE
O/LOOP INTERNAL S-RAMP
0-10V ANALOGUE - 0 TO 10Vdc
4-20mA ANALOGUE - 4 TO 20mA
TACHO PULSE TACHO INPUT (TACHO FEEDBACK)
FREQUENCY INPUT SOURCES (SCREEN 64)
CODE CONTROL SOURCE
0-10V ANALOGUE - 0 TO 10Vdc
4-20mA ANALOGUE - 4 TO 20mA
V/mA MAXIMUM OF 0-10V OR 4-20mA
TACHO PULSE TACHO INPUT (TACHO FOLLOW)
KEYBD LOCAL KEYBOARD CONTROL
COMMS SERIAL COMMUNICATIONS
Table 2.1.2 Display Screen Messages - Full Menu Modes
WARNING MESSAGES:
MESSAGE MEANING/NOTES
STOP TO ALTER ADJUSTMENT CAN ONLY BE MADE WITH DRIVE STOPPED
ILLEGAL ACCESS DRIVE MUST BE IN COMMISSIONING MODE TO ADJUST SETTINGS
NO KEYBD CONTROL KEYBOARD CONTROLS ARE NOT ENABLED
INITIALISING DRIVE BEING INITIALISED TO FACTORY DEFAULT SETTINGS
