Microdrive Series Instruction Manual
4201-109 Rev I
94
APPENDIX 2: MICRODRIVE-3 (UD3) SPARES LISTS
Model Part No. Rec. Qty
UD3-22.5
UD3 control PCB assembly 0265-601S 1
UD3-22.5 power PCB assembly 0270-610 1
Thermstrate: IGBT 1781-107 1
Thermstrate: rectifier 1781-205 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 175mm 2725-003 1
Fan: 24Vdc, 38x119 2941-006 1
UD3-31
UD3 control PCB assembly 0265-601S 1
UD3-31 power PCB assembly 0271-610 1
UD3 31/46 snubber PCB 0271-611 1
Thermstrate: IGBT 1781-003 3
Thermstrate: rectifier 1781-205 1
Fuse link: 2A 440V ceramic 2401-004 2
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 175mm 2725-003 1
Fan: 24Vdc, 38x119 2941-006 2
UD3-46
UD3 control PCB assembly 0265-601S 1
UD3-46 power PCB assembly 0272-610 1
UD3 31/46 snubber PCB 0271-611 1
Thermstrate: IGBT 1781-104 3
Thermstrate: rectifier 1781-205 1
Fuse link: 2A 440V ceramic 2401-004 2
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 175mm 2725-003 1
Fan: 24Vdc, 38x119 2941-006 2
UD3-60
UD3 control PCB assembly 0265-601S 1
UD3-60 power PCB assembly 0274-610 1
UD3 31/46 snubber PCB 0271-611 1
Thermstrate: IGBT 1781-104 3
Thermstrate: rectifier 1781-504 3
Fuse link: 2A 440V ceramic 2401-004 2
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 175mm 2725-003 1
Fan: 24Vdc, 38x119 2941-006 3
UD3-70
UD3 control PCB assembly 0265-601S 1
UD3-70 power PCB assembly 0273-610 1
UD3 31/46 snubber PCB 0271-611 1
Thermstrate: IGBT 1781-104 3
Thermstrate: rectifier 1781-504 3
Fuse link: 2A 440V ceramic 2401-004 2
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 175mm 2725-003 1
Fan: 24Vdc, 38x119 2941-006 3
Notes: Due to the high cost and difficulty of replacement
of power PCBs, in critical applications it will
often be more practical to stock a spare UD3
for service use.
Model Part No. Rec. Qty
UD3-2.5
UD3 control PCB assembly 0265-601S 1
UD3-2.5 power PCB assembly 0266-610 1
Thermstrate: IGBT 1781-502 1
Thermstrate: rectifier 1781-204 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 125mm 2725-002 1
Fan: 24Vdc, 38x119 2941-006 1
UD3-6.5
UD3 control PCB assembly 0265-601S 1
UD3-6.5 power PCB assembly 0267-610 1
Thermstrate: IGBT 1781-502 1
Thermstrate: rectifier 1781-204 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 125m 2725-002 1
Fan: 24Vdc, 38x119 2941-006 1
UD3-10.5
UD3 control PCB assembly 0265-601S 1
UD3-10.5 power PCB assembly 0268-610 1
Thermstrate: IGBT 1781-107 1
Thermstrate: rectifier 1781-204 1
Thermstrate: rectifier packer 1781-205 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 125mm 2725-002 1
Fan: 24Vdc, 38x119 2941-006 1
UD3-12
UD3 control PCB assembly 0265-601S 1
UD3-12 power PCB assembly 0264-610 1
Thermstrate: IGBT 1781-107 1
Thermstrate: rectifier 1781-204 1
Thermstrate: rectifier packer 1781-205 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 125mm 2725-002 1
Fan: 24Vdc, 38x119 2941-006 1
UD3-16
UD3 control PCB assembly 0265-601S 1
UD3-16 power PCB assembly 0269-610 1
Thermstrate: IGBT 1781-107 1
Thermstrate: rectifier 1781-204 1
Thermstrate: rectifier packer 1781-205 1
Fuse link: 2A glass, 20x5 2401-017 2
Flat film cable: 125mm 2725-002 1
Fan: 24Vdc, 38x119 2941-006 1
