Page #19 background imageLoading...
Page #19 background image
User Manual PEAK INSTRUMENTS INC
16
1.1. Communication port inspection
Check the communication port of the instrument is working properly or not. The
result is displayed correctly as √ and an error as ×, the buzzer alarm.
1.2. File system check
Check the instrument's built-in flash file system is correct. The result is
displayed correctly √, an error will reformat the file system.
1.3. Filter positioning
Check the instrument's filter motor and its locator is working correctly. The result
is displayed correct as √, an error as ×, the buzzer alarm.
1.4. Light positioning
Check the instrument light switch motor and its locator is working correctly. The
result is displayed correctly √, an error is displayed result is ×, the buzzer alarm.
1.5. Printer check
Check the printer interface device is working properly. The result is displayed
correctly √, an error is displayed result is ×, the buzzer alarm.
1.6. Tungsten lamp examination
Open the instrument tungsten light source, check the operating parameters of
tungsten lights are working properly. If the parameter is not working properly,
then re-set the operating parameters of a tungsten lamp. Change detections are
always displayed correctly, the result is always √.
1.7. Deuterium lamp examination
Open deuterium light source instrument operating parameters to check the
deuterium lamp is working correctly. If the parameter is not working properly,
then re-set the operating parameters of the deuterium lamp. Change detections
are always displayed correctly, the result is always √.
1.8. Signal detector check
Check signal detector instrument is working correctly. The result is displayed
correctly √, an error is displayed result is ×, the buzzer alarm.
1.9. Wavelength Calibration
Wavelength parameter checking instrument is working properly. Correct, then
the pop-up boxes, please confirm whether the user input wavelength calibration
if no user input within five seconds, then skip this. If the argument is wrong
wavelength, then start looking for a deuterium lamp to automatically correct the
characteristic peak wavelength. Wavelength calibration result is displayed by √,
the correction is not passed, then the result is ×, the buzzer alarm.
1.10. Dark current correction
Read instrument dark current of energy, checking eligibility. If the dark current in
the proper range, which means that the dark current is correct, then displays the
