User Manual PEAK INSTRUMENTS INC
27
5.2.1. Set start wavelength and end wavelength
The start wavelength and end wavelength mean the wavelength range used for
scanning.
5.2.2. Set the measurement mode
The measurement mode is absorbance, transmission or energy. Choose
different measurement mode, you need to re-set the display to display the upper
and lower limits.
5.2.3. Set upper and lower limit
The different measurement modes: upper and lower display is not the same.
5.2.4. Set wavelength scan interval
Scan scanning wavelength interval from 0.1nm to 5.0nm.
5.2.5. Set scanning speed
The scanning speed determines the quantity of data collecting on single point
wavelength. The faster the speed, the less the collecting quantity.
5.2.6. Select to make data smoothing
The function for data smoothing is to reduce the irregular fluctuation caused by
external environment during testing.
Note: You must set the scan settings before calibration parameters blank,
because the scan settings to modify the parameters, the baseline will lead to an
invalid user, the user needs to re-establish a baseline.
5.3. System baseline
Before the beginning of the measurement wavelength scan, you must create a
system baseline. If you have previously established a system baseline, you can
skip. A long time without updating the system, re-create the system baseline.
