4. Manual air override button is provided for inspection and troubleshooting
the pneumatic system.
a. It must be deactivated in normal run mode (gage pressure will read
zero).
Electrical Disconnect
Note: The Electrical Disconnect is located on the front of the Main Electrical Panel.
1. To disconnect power from the Main Electrical
Panel, turn the Main Electrical Disconnect to
the OFF position.
2. Follow your company's lock out/tag out
procedures.
3. To reconnect power, turn the Main Electrical
Disconnect to the ON position.
Operations Manual CE35-T Case Erector
M-CE35T-2c Horiz Mag 3/2/2010
Machine Safety
17
Fig. 8: Main Electrical
Disconnect Switch
Fig. 9: Manual Air Override Button On The Air Dump Valve
Air Dump
Valve,
Manual
Override
Button
