Pearson CE35-T Case - Human-Machine Interface (HMI); Electronic Operator Interface

Human-Machine Interface (HMI)
In This Chapter
This Chapter provides information on the display screens located in the Allen Bradley
PanelView Plus 600 Operator Interface; the layout and function of each screen.
Electronic Operator Interface
The Allen-Bradley PanelView Plus 600 is
an electronic operator interface — the
operator gathers information from the LED
display and presses the touch screen to
perform a particular function. Some items
in the PanelView can be changed directly
by any operator (such as choosing case
size) while other items require a password
(such as servo motor parameters). This
section is intended to describe the screens
and functions specific to the Pearson
Packaging Systems CE35-T Case Erector.
For technical information about the
Allen-Bradley PanelView Plus 600, refer
to the manual shipped with this machine or
visit Allen-Bradley’s web site at http://www.ab.com.
Operations Manual CE35-T Case Erector
M-CE35T-2c Horiz Mag 3/2/2010
Human-Machine Interface
(HMI)
67
Fig. 63: Allen-Bradley PanelView Plus
600
