6. The set-up arm cylinder has a sensor which triggers the set-up arm alarm.
7. The set-up arm alarm is a time-based fault alarm. If the sensor is not flagged
within a certain amount of time during operation the program will register a
fault alarm and shut down the machine.
Operations Manual CE35-T Case Erector
M-CE35T-2c Horiz Mag 3/2/2010
Machine Operation
41
Fig. 31: Set-up Arm Alarm Sensor
Set-up Arm
Alarm Sensor
