Pendulum CNT-90 - Default Settings (after * RST)

Default settings
(after
*
RST)
PARAMETER VALUE/
SETTING
Inputs A & B
Trigger Level AUTO
Impedance
1MW
Manual Attenuator 1X
Coupling AC
Trigger Slope POS
Filter OFF
Arming
Start OFF
Start Slope POS
Start Arm Delay 0
Stop OFF
Stop Slope POS
Source IMM
Hold-Off
Hold-Off State OFF
Hold-Off Time 200 ms
Time-Out
Time-Out State OFF
Time-Out Time 100 ms
Statistics
Statistics State OFF
No. of Samples 100
No. of Bins 20
Pacing State OFF
Pacing Time 20 ms
PARAMETER VALUE/
SETTING
Mathematics
Mathematics State OFF
Constants K=M=1,
L=0
Limits
Limit State OFF
Limit Mode RANGE
Lower Limit 0
Upper Limit 0
Burst
Sync Delay 400 ms
Start Delay 0
Meas. Time 200 ms
Freq. Limit 300 MHz
Miscellaneous
Function FREQ A
Smart Frequency AUTO
Smart Time Interval OFF
Meas. Time 10 ms
Memory Protection
(Memory 1 to 10)
Not
changed by
*
RST
Auto Trig Low Freq Lim 100 Hz
Timebase Reference AUTO
Arm-Trig State IDLE
(equivalent
to sending
:INIT:CONT
OFF)
2-2 Default settings (after
*
RST)
Default Settings
