Installer manual Autotrol 368 (604-606) - System sizing
Ref. MKT-IM-007 / D - 09.10.2020 19 / 60
4 System sizing
4.1 Injector/DLFC/Refill flow controller - Valve configuration
Vessel
diameter
[In]
Injector Flow
control
Refill flow
control
[gpm]
Backwash flow
control
[gpm]
Controller
Time Clock 604
Controller
Volumetric 606
6 E [yellow] 0.14 0.9 4001737 4001738
7 F [peach] 0.14 1.2 4001737 4001738
8 G [tan] 0.14 1.6 4001737 4001738
9 H [lt purple] 0.14 2.0 4001737 4001738
10 J [lt blue] 0.33 2.5 4001741 4001742
4.2 Cycle time calculation
The 600 series controller will automatically set the cycle time based on the program or so called
unit number selected when programming the system (see System selection [
Page35]). Make
sure the programmed unit# is corresponding to your actual system and valve configuration.
4.3 Salt amount definition
The salt amount is set in kilograms of salt use for each regeneration. This setting will greatly
influence the system. Make sure this setting is aligned with your actual system size and unit#
programmed.
4.4 Injector flow rates
The following graphs represent the injectors flow rate as a function of the inlet pressure for the
different injector sizes.
