INTELLICHEM
®
Controller Installation and User’s Guide
INTELLICHEM
®
Controller Installation and User’s Guide
55
2
1
5
23
3
6
7
9
8
IntelliChem
®
Controller Flow Cell Replacement Parts List
1. P/N 522186 - Sensor, pH (* 1 year warranty)
2. P/N 522187 - Sensor, ORP (* 1 year warranty)
3. P/N 754000310 - Flow Cell with Flow Switch Sensors
4. P/N 521342Z - IntelliChem Controller Parts Bag (not shown)
5. P/N 754000440 - Flow Switch Sensor with Magnet
P/N 754000410 - Magnet for Flow Switch
6. P/N 744000290 - Cable, pH 3 ft
7. P/N 744000360 - Cable, ORP 3 ft
8. P/N 754000340 - O-Ring for Flow Jar
9. P/N 754000350 - Flow Jar
Accessories:
P/N 521814 - 3/8” Black Tubing (optional)
P/N 744000280 - Cable, pH 10 ft (optional)
P/N 744000350 - Cable, ORP 10 ft (optional)
* Warranty Information
The IntelliChem Controller
pH Sensor and ORP Sensor
each have a one year limited
warranty.
The IntelliChem Controller
pump head, pH Sensor and
ORP Sensor are considered
wear items and are covered by
their own warranty periods and
are not part of any extended
warranty coverage.
For more information contact Customer Support (800) 831-7133
