MAIN SCREEN
PH MENU
pH Dosage (Page 1/2) Dosage (For liquid; Volume/Time):
(For CO2; Time or to set point): Mixing Time: H:24 M:59
pH Dose by Volume (Page 2/2) Dose: [0-9999], Limit: [0-64350],
Units: [oz/ml], Clear [Manual]
pH Dose by Time (Page 2/2) Dose: [00:00:00], Limit: [00:00:00], Clear: [Power-On]
pH Dose to Setpoint (Page 2/2) Limit: [00:00:00], Clear: [24hr Flow]
pH Setpt: 7.5 (use Left/Right button to adjust pH set point)
pH Tweak - reading = 7.xx tweak: 0.0 (+/- 0.3)
pH Supply (Page 1/2) Units: gal-US/gal-UK/Liters/Time, Chemical: [Acid, pH-, Base, pH+] -
Page 2/2 - Capacity: 0.000-200.00 gal-US/galUK/Liters - Gauge: Egg timer or tank gauge -
Page 2/2 Time: Reminder in: H:100 M:00
Sensitivity: - [Low/High/Off] - Full Dose at 0.5pH (Low - Liquid, CO2),
(High 0.2pH from set point).
pH Alarms: Page1/2 High 7.8 - Delay 00:05:00 - Page 2/2 Low: 6.8 Delay 00:05:00
AUTO SETUP
See page 6 for details
SAT INDEX
- CH: xxx - SLT: xxx - TA:xx = CYA: xx Recalc/Tab:
(page 11)
ORP MENU
ORP Dosage (Page 1/2) Dosage (For liquid; Volume/Time):
(For SCG; Time or to set point): Mixing Time: H:24 M:59
ORP Dose by Volume (Page 2/2) Dose: [0-9999], Limit: [0-64350], Units: [oz/ml], Clear [Manual]
ORP Dose by Time (Page 2/2) Dose: [00:00:00], Limit: [00:00:00], Clear: [Power-On]
ORP Dose to Setpoint (Page 2/2) Limit: [00:00:00], Clear: [24hr Flow]
ORP Setpt: 700 (use Left/Right button to adjust ORP set point)
ORP Tweak - reading = xxx tweak: 0.0 (+/- 50mV)
ORP Supply (Page 1/2) Units: gal-US/gal-UK/Liters/Time, Chemical: [Chlorine/Bromine] -
Page 2/2 - Capacity: 0.000-200.00 gal-US/galUK/Liters - Gauge: Egg timer or tank gauge -
Gauge: Egg Timer or tank gauge - Page 2/2 Time: Reminder in: H:100 M:00
Sensitivity: - [Low/High/Off] - Full Dose at 50 mV ORP (Low - Liquid),
(High 20 mV from set point, Off (IntelliChlor OFF)
ORP Alarms: Page1/2 High 750 - Delay 01:00:00 - Page 2/2 Low: 650 Delay 02:00:00
(page 14)
CONFIGURATION
Pool Details:Volume: 0.2K-230K (200-230,000 Liters max) Units:
Gal US (gal-US/gal-UK/Liters), Daily Hrs/Mins
Display Mode: Display Mode: Basic/Advanced, Brightness Front LEDs: (0-100%),
Menu/BkLt Hrs/Mins. (24 hrs -30sec.)
Delays: Power-on: 1-60 mins. (15min default) - FlowSwitch: 1-60 mins. (1 min default) -
Doser/Probe: Seconds 0,15,30,60secs.
Set Password: PW [1234] - Lock [OFF/MENU/ALL]
Preferences: pH Lockout: 7.8, Preferences 2/2: Saturation Index, Alarm: +/- 0.3,
Dose Priority: [Simultaneous pH Priority]
Diagnostics: Software Rev, Meter Test {Auto Calibration),
Probe Test (Open Probe Test) Timers,
Chlorinator, Status Codes, Factory Reset, Self Test Sequence
Hardware: pH Control: 1/2 Doser Type [Internal Pump, External/Relay,
CO2 Ext/Relay, None] - pH Control 2/2 Flow: xx GPD
(page 17)
See page 22 for details
See page 24 for details - pH: 7.5 - Temp: 00°F -
