VMP2 VMP1-IO1 Module (Optional)
ID 24855, Rev. 02 Page A - 7© 2002 PEP Modular Computers GmbH
A.5 Technical Specifications
Table A-1: VMP1-IO1 Specifications
VMP1-IO1 Specifications
PCI-Standard Compliant with PCI 2.1
Signaling Voltage PMC-Side: 5V signaling
Connectors PMC Jn1 (CON4) and Jn2 (CON5) connectors
Mechanical Compliance
IEEE 1101.10
CMC IEEE P1386/Draft 2.0 (with minor
exceptions)
Temperature Range
Operation:
• -40° to +85°C
Storage:
• -55° to +85°C
Operating Humidity 5 – 95% (non condensing)
Vibrations and
Broad-Band Random Vibration
IEC68-2-6 compliant
IEC68-2-64
Shocks:
Permanent Shocks
Single Shock
IEC68-2-29
IEC68-2-27
Board Dimensions
Single-height Eurocard:
100 mm x 160 mm
1 x 4 HP slot
Board Weight 114 grams
