PEP Modular Computers VMP2 - Eeprom; Digital Temperature Sensor

VMP2 Configuration
ID 24855, Rev. 02 Page 4 - 21© 2002 PEP Modular Computers GmbH
4.3.7 EEPROM
Access to the EEPROM is effected via the I2C bus of the MPC8245. The EEPROM
uses the I2C address 0xA0.
For more detailed information please refer to the manuals for the MICROCHIP 24LC16B
and the MOTOROLA MPC8245 (I2C bus).
4.3.8 Digital Temperature Sensor
Access to the onboard temperature sensor is effected via the I2C bus of the MPC8245.
The EEPROM uses the I2C address 0x90.
For more detailed information please refer to the manuals for the National Semiconduc-
tor LM75 and the MOTOROLA MPC8245 (I2C bus).
