A.7 Pinouts
A.7.1 Jn1 (CON4) Pin Assignment
Table A-2: Jn1, 32-bit PCI
Pin Number Signal Name Signal Name Pin Number
1TCK-12V2
3GroundINTA#4
5INTB#INTC#6
7BUSMODE1#+5V8
9 INTD# PCI-RSVD* 10
11 Ground PCI-RSVD* 12
13 CLK Ground 14
15 Ground GNT# 16
17 REQ# +5V 18
19 V(I/O) AD[31] 20
21 AD[28] AD[27] 22
23 AD[25] Ground 24
25 Ground C/BE[3]# 26
27 AD[22] AD[21] 28
29 AD[19] +5V 30
31 V(I/O) AD[17] 32
33 FRAME# Ground 34
35 Ground IRDY# 36
37 DEVSEL# +5V 38
39 Ground LOCK# 40
41 SDONE# SBO# 42
43 PAR Ground 44
45 V(I/O) AD[15] 46
47 AD[12] AD[11] 48
49 AD[09] +5V 50
51 Ground C/BE[0]# 52
53 AD[06] AD[05] 54
55 AD[04] Ground 56
57 V(I/O) AD[03] 58
59 AD[02] AD[01] 60
61 AD[00] +5V 62
63 Ground REQ64# 64
