VMP2 Configuration
ID 24855, Rev. 02 Page 4 - 19© 2002 PEP Modular Computers GmbH
4.3.5 IRQ Routing
Table 4-21: Serial IRQ’s
IRQ Name Source
S_IRQ0 Reserved
S_IRQ1 UART-A
S_IRQ2 UART-B
S_IRQ3 INTA# (PCI)
S_IRQ4 INTB# (PCI)
S_IRQ5 INTC# (PCI)
S_IRQ6 INTD# (PCI)
S_IRQ7 Temperature sensor interrupt
S_IRQ8 LINT0# / VME Interrupt level 1 and 2
S_IRQ9 LINT1# / unused
S_IRQ10 LINT2# / VME Interrupt level 3 and 4
S_IRQ11 LINT3# / VME Interrupt level 5 and 6
S_IRQ12 LINT4# / VME Interrupt level 7 + SYSFAIL
S_IRQ13 LINT5# / VME ACFAIL
S_IRQ14 LINT6# / 4 location monitors
S_IRQ15 LINT7# / 4 mailboxes
