VMP2 VMP1-IO1 Module (Optional)
ID 24855, Rev. 02 Page A - 11© 2002 PEP Modular Computers GmbH
A.7.2 Jn2 (CON5) Pin Assignment
Table A-3: Jn2, 32-bit PCI
Pin Number Signal Name Signal Name Pin Number
1 +12V TRST# 2
3TMSTDO4
5 TDI Ground 6
7 Ground PCI-RSVD* 8
9 PCI-RSVD* PCI-RSVD* 10
11 BUSMODE2# +3.3V 12
13 RST# BUSMODE3# 14
15 3.3V BUSMODE4# 16
17 PCI-RSVD* Ground 18
19 AD[30] AD[29] 20
21 Ground AD[26] 22
23 AD[24] +3.3V 24
25 IDSEL AD[23] 26
27 +3.3V AD[20] 28
29 AD[18] Ground 30
31 AD[16] C/BE[2]# 32
33 Ground PMC-RSVD 34
35 TRDY# +3.3V 36
37 Ground STOP# 38
39 PERR# Ground 40
41 +3.3V SERR# 42
43 C/BE[1]# Ground 44
45 AD[14] AD[13] 46
47 Ground AD[10] 48
49 AD[08] +3.3V 50
51 AD[07] PMC-RSVD 52
53 +3.3V PMC-RSVD 54
55 PMC-RSVD Ground 56
57 PMC-RSVD PMC-RSVD 58
59 Ground PMC-RSVD 60
61 ACK64# +3.3V 62
63 Ground PMC-RSVD 64
