1.3 VMP2 Main Specifications
Table 1-1: VMP2 Main Specifications
VMP2 Specifications
Operating System
Support
Initial boot loader with capability to load VxWorks and other
Real-time operating systems
VME Interface
ANSI/VITA 1-1994 for VME, approved April 10, 1995
Support for A24: D16/D8 master and A24: D16/D8 slave
interface
Processor
Motorola MPC8245, 330 MHz with integrated PCI interface
Boot Device
8 MB Flash for bootloader and ROMable OS/Socket
Main Memory
32 MB, 64 MB, 128 MB and 256 MB of onboard SDRAM with
ECC support available as standard
Cache Structure
16K, 32 byte line, 4-way set associative instruction cache
16K, 32 byte line, 4-way set associative data cache
Flash
8 MB on-board Flash (soldered)
DIL600 Socket
Socket for Flash extension by another 512 kB or addition of
Flash disk (M-System) with up to 144 MB
PCI Expansion Connector
1 x Samtec SMT Board-to-Board connector 100-pin
order number: FLE - 15 - 01 - G - DV
Ethernet
10Base-T / 100Base-TX
SRAM
256 or 512 kB NV SRAM on the DIL600 socket
Serial Port
16550 compatible Dual UART; 2 x RS-232 or
1 x RS232 + 1 x RS485
Watchdog
Watchdog generates Exception Condition / Reset or NMI
(software configurable)
RTC
backed up with GoldCap / Data retention for about 5 days /
backup battery possible
EEPROM
1 x 24LC16 for special purposes (8x256Byte)
LED’s
6 LED’s:
red = general purpose
yellow = watchdog active
green = general purpose
green = Ethernet Link Integrity,
green = Ethernet Activity
green = Ethernet Speed
Switches
Two push-buttons (Reset and Abort)
