VMP2 Introduction
ID 24855, Rev. 02 Page 1 - 7© 2002 PEP Modular Computers GmbH
Debug Interface
JTAG/BDM
VME Connector
96-pin VME connector
Onboard Connectors
2 x RJ45 for RS232, 1 x RJ45 for Ethernet
PCI Expansion Modules
PMC carrier, future PCI based I/O board with
VGA/SCSI/2
nd
Ethernet
Mechanical Conformance
Conforms with IEEE 1101.10
Power Supply
5V in accordance with the VME Specification, 1.31 Amp
current (at 330 MHz)
Temperature Range
–40°C to +85°C (operating)
–55°C to +125°C (storage)
Humidity
0% to 95% non-condensing
Dimensions
100mm x 160mm single-height Eurocard
Board Weight
182 grams
Table 1-1: VMP2 Main Specifications (Continued)
VMP2 Specifications
