2.2 Front Panels
Figure 2-2: Front Panels
Standard VMP2 and
VMP2 Optoisolated version
and Optoisolated version
with IO1 Module - note the
different position of the
SER 0 connector
Standard with IO1 Module
VMP1-IO1
VMP1VMP1
WUH WUH
ABRST
LNK.
SPEEDACT.
ABRST
LNK.
SPEEDACT.
VMP1
VMP1-IO1
VMP1
WUH
ABRST
LNK.
SPEEDACT.
ABRST
LNK.
SPEEDACT.
W
UH
KEY
LED colors
U = green
W = yellow
H = red
(for B&W monitors
and printouts):
