PEP Modular Computers VMP2 - Serial Interface Expansion Connector (CON3); RS Expansion Connector Pinout

VMP2 Configuration
ID 24855, Rev. 02Page 4 - 6 © 2002 PEP Modular Computers GmbH
4.2.2 Serial Interface Expansion Connector (CON3)
Table 4-5: RS Expansion Connector Pinout
Pin Number Function Function Pin Number
1GNDRTSB2
3REDE4
5RxDTxD6
7CTSDTR8
9SCLSDA10
11 +3.3V VCC 12
