VMP2 VMP1-IO1 Module (Optional)
ID 24855, Rev. 02 Page A - 9© 2002 PEP Modular Computers GmbH
Figure A-3: Installation Diagrams
2
1
VMP1-IO1 Front Panel
PMC module
VMP1-IO1
3
10mm stand-off
PMC bezel
4 *M2.5 *6mm
screws
