VMP2 JTAG Subsystem
ID 24855, Rev. 02Page D - 4 © 2002 PEP Modular Computers GmbH
If EMULATOR access to the MPC8245 is required it must be ensured that R94 and
R183 are set and also that R104 and R180 are removed (all resistors are 0R).
Figure D-2: Resistor Positions on Reverse of VMP2 Board
SDRAM MEMORY
BANK 2
R3
R11R12R13
R8 R6R7
MAGNIFIED SECTION
R104
R94
R106
R183
R180
R90
R104
R94
R106
R183
R180
R90
Please note that
this diagram is
not to scale with
other board
diagrams
Resistors relevant
to the JTAG
Subsystem appear
on the magnified
section of the board
