K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
29
Value
Function
0.01
Frequency = 0 Hz for frequencies less than 100 Hz
1.00
Default value
79.99
Frequency = 0 Hz for frequencies less than ~ 0.01 Hz
AVERAGE FILTER 2 (average determination)
Switchable average determination or filter function at unstable frequencies at
input B for smoothing the analog signal. If the filter is set to 5 … 16, the device
uses an exponential function. The time constant T (63 %) corresponds to the
number of sampling cycles.
E.g., SAMPLING TIME = 0.1 s and AVERAGE FILTER = exponential filter,
T (63 %) = 2 x sampling time.
This means that after 0.2 s, 63 % of the jump height is reached.
Value
Function
0
No average determination
(quick response to any change)
1
Flowing average determination with two cycles
2
Flowing average determination with four cycles
3
Flowing average determination with eight cycles
4
Flowing average determination with 16 cycles
5
Exponential filter, T (63 %) = 2x SAMPLING TIME
6
Exponential filter, T (63 %) = 4x SAMPLING TIME
7
Exponential filter, T (63 %) = 8x SAMPLING TIME
8
Exponential filter, T (63 %) = 16x SAMPLING TIME
9
Exponential filter, T (63 %) = 32x SAMPLING TIME
10
Exponential filter, T (63 %) = 64x SAMPLING TIME
11
Exponential filter, T (63 %) = 128x SAMPLING TIME
12
Exponential filter, T (63 %) = 256x SAMPLING TIME
13
Exponential filter, T (63 %) = 512x SAMPLING TIME
14
Exponential filter, T (63 %) = 1024x SAMPLING TIME
15
Exponential filter, T (63 %) = 2048x SAMPLING TIME
16
Exponential filter, T (63 %) = 4096x SAMPLING TIME
(very slow reaction)
