K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
39
SERIAL BAUD RATE
This parameter is used to set the serial baud rate.
Value
Designation
Function
0
9600
-
1
19,200
-
2
38,400
-
3
115200
115200 baud
Note
The baud rate is fixed to 115200 for USB interface and cannot be adjusted.
SERIAL FORMAT
This parameter sets the bit data format.
Value
Designation
Function
0
7-EVEN-1
7 data Parity even 1 stop
1
7-EVEN-2
7 data Parity even 2 stops
2
7-ODD-1
7 data Parity odd 1 stop
3
7-ODD-2
7 data Parity odd 2 stops
4
7-NONE-1
7 data No parity 1 stop
5
7-NONE-2
7 data No parity 2 stops
6
8-EVEN-1
8 data Parity even 1 stop
7
8-ODD-1
8 data Parity odd 1 stop
8
8-NONE-1
8 data No parity 1 stop
9
8-NONE-2
8 data No parity 2 stops
Note
The Serial data format is fixed to 8-none-1 for USB interface and cannot be adjusted.
