K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
40
SERIAL INIT
This parameter determines the baud rate at which the initialization values are
transferred to the PC user interface. When set to greater than 9600 baud, the
duration of the initialization can be shortened.
Value
Designation
Function
0
NO
The initialization values are transferred at 9600
baud. The device then works again at the value set
by the user
1
YES
The initialization values are transmitted at the baud
rate set by the user in the SERIAL BAUD RATE
parameter. The device then continues to work at
the value set by the user
SERIAL PROTOCOL
Specifies the string for command-controlled or timed transmissions
(xxxxxxx = SERIAL VALUE).
At default 1, the unit no. is omitted and the transmission starts directly with the
measured value, which enables a quicker transmission cycle.
Value
Function
0
Transmission protocol = unit no., +/-, data, LF, CR
1
1
+/-
X
X
X
X
X
X
X
LF
CR
1
Transmission protocol = +/-, data, LF, CR
+/-
X
X
X
X
X
X
X
LF
CR
SERIAL TIMER (S)
Adjustable time cycle in seconds for automatic (cyclical) transmission of the
SERIAL VALUE via the serial interface.
In the event of a request via the request protocol, the cyclical transmission is
interrupted for 20 seconds.
Value
Function
0.000
Cyclical transmission is switched off and the device only
sends SERIAL PRINT on command via a control input or
request via request protocol
…
60.000
Time cycle in seconds.
