K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
41
SERIAL VALUE
The parameter determines which value is transmitted.
Value
Code
Function
0
:0
Measurement_Result (Result after linking, scaling,
filter, etc.)
1
:1
Converted_Output_Value (Parallel output data after
conversion)
2
:2
Frequency_1 (measured frequency - channel A
without scaling)
3
:3
Frequency_2 (measured frequency - channel B
without scaling)
4
:4
Counter (total count after linking without scaling,
filters, etc.)
5
:5
Counter_A (counter reading - channel A)
6
:6
Counter_B (counter reading - channel B)
7
:7
SSI_Data (read + possibly converted binary SSI
value)
8
:8
SSI_Calc_Result (SSI value incl. SSI zero and SSI
offset without scaling, filters, etc.)
9
:9
Minimum_Value (Minimum value of
Measurement_Result)
10
;0
Maximum_Value (Maximum value of
Measurement_Result)
11
;1
Reserve
12
;2
Reserve
13
;3
Error Status (Reading the error code)
14
;4
SSI Read Value (readed, unconverted SSI value)
15
;5
SSI Loop Value (SSI value after round loop
calculation)
16
;6
Actual Speed ()
17
;7
Actual Position (Start Stop: position [in µm] with
offset without scaling)
18
;8
Actual Angle (Start Stop: e.g. angle with offset
without scaling)
19
;9
Raw Position (Start Stop: position [in µm] without
Offset and without scaling)
