VisuNet FLX System
Installing Peripherals
2023-11
99
10. Connect the plug of the barcode reader connection cable or base station connection cable to
the M12 connector of the adapter and tighten it firmly.
Figure 7.21
Figure 7.22 The plug and socket are coded. Match the coding on the plug and socket before
tightening.
Coded Plug and Socket
Note
For further information regarding the IDM Zone 2/22 barcode reader portfolio
refer to the IDM barcode reader manuals.
