Pepwave AP One Series User Manual

http://www.pepwave.com 36 Copyright © 5/23/16 Pepwave
User Manual
PEPWAVE AP Series
Client Upstream
Enter a value in kpbs to limit connected clients’ upstream bandwidth. Enter 0 to allow Limit
unlimited upstream bandwidth.
Client Enter a value in kpbs to limit connected clients’ downstream bandwidth. Enter 0 to allow
Downstream Limit unlimited downstream bandwidth.
Firewall Settings
Firewall Mode
Choose Flexible – Allow all except… or Lockdown – Block all except… to turn on the firewall,
then create rules for the firewall exceptions by clicking . See the discussion below
for details on creating a firewall rule. To delete a rule, click the associated button.
To turn off the firewall, select Disable.
Firewall Rule
Name
Enter a descriptive name for the firewall rule in this field.
Type
Choose Port, Domain, IP Address, or MAC Address to allow or deny traffic from any of those
identifiers. Depending on the option chosen, the following fields will vary.
Protocol / Port
Choose TCP or UDP from the Protocol drop-down menu to allow or deny traffic using either of
those protocols. From the Port drop-down menu, choose Any Port to allow or deny TCP or UDP
traffic on any port. Choose Single Port and then enter a port number in the provided field to
allow or block TCP or UDP traffic from that port only. You can also choose Port Range and enter
a range of ports in the provided fields to allow or deny TCP or UDP traffic from the specified
port range.
IP Address /
Subnet Mask
If you have chosen IP Address as your firewall rule type, enter the IP address and subnet mask
identifying the subnet to allow or deny.

Pepwave AP One Series Specifications

General

Wi-Fi Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz, 5 GHz
Ethernet Ports	2 x Gigabit Ethernet
Security	WPA3, WPA2, WEP
Antennas	Internal antennas
Mounting	Wall or ceiling mount
Power over Ethernet (PoE)	802.3af/at
