104 KENR9126
Troubleshooting Section
Table 22
T rip Points for Low Oil Pressure Warning
0rpm
0kPa(0psi)
500 rpm
0kPa(0psi)
1600 rpm
154kPa(22psi)
2400 rpm
154kPa(22psi)
Table 23
Trip Points for Low Oil Pressure Derate
0rpm
0kPa(0psi)
500 rpm
0kPa(0psi)
1600 rpm 104 kPa (15 psi)
2400 rpm 104 kPa (15 psi)
Table 24
Trip Points for High Fuel Pressure Warning
500 rpm
759 kPa
(110 psi)
2000 rpm
794 kPa (115 psi)
Table 25
Trip Points for Low Fuel Pressure Warning
500 rpm
350kPa(51psi)
700 rpm
380kPa(55psi)
980 rpm
390kPa(57psi)
1100 rpm
400kPa(58psi)
2300 rpm
400kPa(58psi)
2600 rpm
410kPa(59psi)
i0
4018129
E096 High Fuel Pressu re
C
onditions Which Generate This Code:
This event code will only be generated if the sensor
f
or high fuel pressure is installed and correctly
wired to the ECM. The feature must be enabled
in the customer programmable parameters on the
electronic service tool.
The Electronic Control Module (ECM) detects a
high fuel pressure. Information on default settings
and ranges for these event codes can be found in
troubleshooting with an event code Troubleshooting,
“Event Codes”.
System Response:
The ECM will log the c ode.
Possible Pe rformance Effect:
Engine performance is not affected.
Check the Low P
ressure Fuel System
Check the components of the low-pressure fuel
system.
Check the pressure of the low-pressure fuel system.
Expected Result:
There is a pr
oblem with the low-pressure fuel system.
Results:
•
OK – There is a problem with the low-pressure
fuel system.
Repair: Make the necessary repairs. Verify that
the repair eliminates the problem.
STOP.
i04022059
E113 Hig h Transmission Oil
Pressure
Condit
ions Which Generate This Code:
This event code will only be generated if the sensor
for th
e transmission oil temperature is installed and
correctly wired to the ECM. The feature must be
enabled in the customer programmable parameters
on the
electronic service tool.
The transmission oil pressure has exceeded the trip
point
. Refer to Troubleshooting, “Event Codes” for
the trip point.
Syst
em Response:
The Electronic Control Module (ECM) will log the
even
t.
Possible Pe rformance Effect:
•
There are no performance effects.
Tro
ubleshooting:
Check the Transmission
Refer to the information that is provided by the OEM
for the transmission.
