Perkins M190C - Page 116

116 KENR9126
Troubleshooting Section
Table 29
P1 Pin Connections
Sensor Pin
Function
Fuel Pressure Sensor Exhaust Gas Temperature
Sensor
1
Volts (5 V)
41 42
2
Ground
33 34
3Signal5654
g02199234
Illustration 15
Typical example
Table 30
P2 Pin Connections
Sensor Pin
Function Fuel Rail
Pressure
Sensor
Intake Manifold
Pressure
Sens
or
Oil Pressure
Sensor
Transmission Oil
Pressure Sensor
1
Volts (5 V)
48 46 46 47
2
Ground
40 38 39 44
3
Signal
51
55
56 54
