Troubleshooting Section
Table 5
Connector
Function
P1 (E-C1) Customer Harness to ECM Connector (64 Pin Connector)
P2 (A-C1) Engine Harness to ECM Connector (64 Pin Connector)
A-C2 Fuel Rail Pump Solenoid Connector (Two Pin Connector)
A-C3 Secondary Speed/Timing Sensor (Two Pin Connector)
A-C4 Primary Speed/Timing Sensor (Two Pin Connector)
A-C5 Engine Oil Pressure Sensor (Three Pin Connector)
A-C6 Fuel Rail Pressure Sensor (Three Pin Connector)
A-C7 Intake Manifold Pressure Sensor (Three Pin Connector)
A-C8 Intake Manifold Air Temperature Sensor (Two Pin Connector)
A-C9 Coolant Temperature Sensor (Two Pin Connector)
E-C3 Diagnos
tic Connector (if equipped)
A-C10 Electronic Unit Injectors for No. 1 and No. 2 Cylinders (Four
Pin Connector)
A-C11 Electronic Unit Injectors for No. 3 and No. 4 Cylinders (Four
Pin Connector)
A-C12 Electronic Unit Injectors for No. 5 and No. 6 Cylinders (Four
Pin Connector)
A-C13 Wastegate regulator (if equipped) (Two Pin Connector)
A-C24 Fuel Temperature Sensor (if equipped) (Two Pin Connector)
A-C15 Fuel Level Sensor (if equipped) (Two Pin Connector)
A-C19 Transmission Oil Temperature Sensor (if equipped) (Two Pin
Connector)
A-C18 Transmission Oil Pressure Sensor (if equipped) (Three Pin
Connector)
A-C14 Fuel Supply Pressure Sensor (if equipped) (Three Pin
Connector)
A-C16 Water In Fuel Sensor (if equipped) (Three Pin Connector)
